| Product Model | HXYD-SH30 | HXYD-SH35 | HXYD-SH40 |
| Air volume handled (m³/h) |
3000 | 3500 | 4000 |
| Motor power (KW) |
2.2 | 3.0 | 4.0 |
| Voltage (V) |
380 | ||
| Filter cartridge specifications (mm) |
φ325*L450 | ||
| Number of filter cartridges |
2 | ||
| Total filtration area (㎡) |
15㎡ | ||
| Filter material | Polyester fiber + PTFE film | ||
| Cleaning method | Pulse cleaning | ||
| Suction arm diameter (mm) |
φ160 | ||
| Suction arm length (m) |
2.2/3.0 | ||
| Filtration accuracy (μm) |
0.3 | ||
| Separation efficiency (%) |
99.9 | ||
| Noise (Db(A)) |
72±3 | 75±3 | 80±2 |
| Overall dimensions (mm) |
800*800*1460 | ||
